Features
1. Main electrical components are from Germany SIEMENS;
2. Adopt twin horizontal shaft forced type concrete mixer, it adopts two heavy duty gear box, electrical lubrication system, hydraulic discharge system, durable mixing device, etc;
3. Excellent environmental protection;
4. Suitable for small-scale construction projects;
5. Accurate weighing system (aggregate, cement, water, additive);
6. PC+PLC control, vividly display the production process on the screen, so that the operator can monitor in real time;
7. save the data of production perimeters in the computer, print daily, monthly or yearly statistic reports of production.
Technical Parameters
Capacity of Mixer
m3
0.75
Discharge Height
m
3.8(for customers choice)
Aggregate Bin Capacity
m3
1.2
Max. Weighing Value of Aggregate
kg
850
Max. Weighing Value of Cement
kg
500
Max. Weighing Value of Water
kg
300
Max. Weighing Value of Additive
kg
30
Aggregate Measuring Accuracy
%
2
Water Measuring Accuracy
%
1
Cement Measuring Accuracy
%
1
Additive Measuring Accuracy
%
1
Cement Screw Conveyor
_
Optional
Cement Silo Capacity
_
Optional
Control Mode
_
Auto/Semi control
